• COMET Y.FXE microfocal X-ray source: FXE-160.50, with TXI function, penetrating X-ray tube head
• HD image processing system: amorphous silicon high-speed flat digital detector 0505J, 16 bit A/D conversion
• X-Y axis sample platform, lead screw drive
• X-ray tube Z-axis electric motion axis
• Rocker control system
• CNC programming function with built-in AXI function for rapid matrix sample detection
• 64-bit Windows 10 operating system with 27" TFT display
• Standard maintenance toolbox
• Super large automatic door
• Detector Z-axis and tilt rotation motion axis

• Microfocus open X-ray tube: FXE-160.50, penetrating X-ray tube head
• High voltage adjustment range: 20~160KV, maximum tube current 1000µA
• Non-crystalline silicon high-definition digital flat panel detector: 130mm x 130mm, 1536x1536 pixels (85µm)
• 6-axis motion system: X/Y stage motion, detector tilt (65°)/rotation, ray tube vertical motion
• Maximum sample size: 645mm x 635mm, maximum weight 5kg
• Computer system: I7-7700K 16GB RAM, 1TB SSD, 8GB graphics card
• Equipment dimensions: 1500mm (L) x 1650mm (W) x 2250mm (H)

• Image Enhancement: Frame superposition, noise removal, edge enhancement for improved clarity
• Manual Measurement Tools: Length, area, curvature, angle measurement and void analysis
• Advanced Automatic Void Measurement: Batch measurement with preset templates and OK/NG judgment
• Automatic Center-Following Motion: X-ray tube and detector synchronous motion technology
• Navigation Automatic Puzzle Function: Image stitching for comprehensive sample analysis
• Automated Reporting: Generates inspection reports with test conditions, images, and results
• Barcode Scanning (Optional): Sample traceability through barcode association
• CNC Automatic Inspection: Preset programs for automated inspection and defect screening
• MES Integration: Customizable system information docking for data upload
• CT Scanning & Analysis: VGSTUDIO 2023.1 Basic Edition for 3D visualization and quality analysis
